The Josef Kihlberg R557PN is a Swedish-made pneumatic roll top stapler designed for fast, high-volume carton sealing. Running JK557 staples in 15–18 mm legs, it uses a 1,000-staple roll to minimise changeovers and keep throughput high. The lightweight composite body (metal wear parts) is compact at 235 × 104 × 205 mm and just 1.8 kg, while quick depth adjustment gives a precise, repeatable stapling cycle. Ideal for NZ packing benches and 3PL lines where loading capacity and speed matter.
Key features
Uses JK557 top-sealing staples; 15–18 mm legs
Roll magazine: 1,000 staples for fewer reloads
Pneumatic drive with easy depth setting
Compact/light: 1.8 kg, 235 × 104 × 205 mm
Max pressure 8 bar (116 psi); oil-lubricated
235 mm reach for easy top closures
Ideal applications
High-throughput carton top sealing
Contract packing, warehousing & 3PL
Manufacturing dispatch and re-pack stations
What’s included
Josef Kihlberg R557PN roll top stapler
User/maintenance documentation
| Weight | 1.8 kg |
|---|---|
| Dimensions | 23.5 × 10.4 × 20.5 cm |
| Brand | Josef Kihlberg |
| Model | R557PN |
| Tool Type | Roll Top Carton Stapler |
| Fastener Type | JK557 staples (roll) |
| Fastener Length | 15–18 mm |
| Activation Method | Sequential |
| Driving System | Pneumatic |
| Operating Pressure | 8 bar |
| Magazine Capacity | 1,000 fasteners |
$1,080.00 + GST
In Stock
Pneumatic roll top stapler for JK557 15–18 mm
1,000-shot roll magazine; rapid loading
Quick depth adjustment; repeatable cycle
1.8 kg compact body; 235 × 104 × 205 mm
Max 8 bar; lubrication required
The Josef Kihlberg R557PN is a Swedish-made pneumatic roll top stapler designed for fast, high-volume carton sealing. Running JK557 staples in 15–18 mm legs, it uses a 1,000-staple roll to minimise changeovers and keep throughput high. The lightweight composite body (metal wear parts) is compact at 235 × 104 × 205 mm and just 1.8 kg, while quick depth adjustment gives a precise, repeatable stapling cycle. Ideal for NZ packing benches and 3PL lines where loading capacity and speed matter.
Key features
Uses JK557 top-sealing staples; 15–18 mm legs
Roll magazine: 1,000 staples for fewer reloads
Pneumatic drive with easy depth setting
Compact/light: 1.8 kg, 235 × 104 × 205 mm
Max pressure 8 bar (116 psi); oil-lubricated
235 mm reach for easy top closures
Ideal applications
High-throughput carton top sealing
Contract packing, warehousing & 3PL
Manufacturing dispatch and re-pack stations
What’s included
Josef Kihlberg R557PN roll top stapler
User/maintenance documentation
| Weight | 1.8 kg |
|---|---|
| Dimensions | 23.5 × 10.4 × 20.5 cm |
| Brand | Josef Kihlberg |
| Model | R557PN |
| Tool Type | Roll Top Carton Stapler |
| Fastener Type | JK557 staples (roll) |
| Fastener Length | 15–18 mm |
| Activation Method | Sequential |
| Driving System | Pneumatic |
| Operating Pressure | 8 bar |
| Magazine Capacity | 1,000 fasteners |
